Spur Gear Motors

SKU D-MR-ER

Robust and Tailored Drive Solutions

Our spur gear motors are characterized above all by one factor: Their robustness.

Description

They allow large radial forces on the output shaft with a wide torque range.

Specifications

Other Features:

  • Torque range from 90 to 550 Nm
  • Excellent degree of performance
  • Coaxial structure
  • 5 sizes of reducers
  • 3 housing finishes









The Advantages at Simple Glance


Maximum Flexibility

  • 5 reducers for torques from 90 to 550 Nm
  • Direct drive or coupling assembly
  • 3 housing finishes


Custom Output

  • Coaxial structure
  • Solid shaft with key


Convenient Online Configuration With Demag Drive Designer

  • Viewing technical data
  • Design support with 2D and 3D geometries in all common file formats
  • Provision of electrical diagrams
  • Display of delivery times
  • Transmission of the individual selection to the Demag Shop



Technical Data

D Spur Gear Motors



Reduction range (I)

Reducer Size

Output Torque [Nm]

2 steps

3 steps

D11

90

2.88 - 66.5

-

D21

130

2.88 - 66.5

-

D31

200

3.23 - 61.6

66.4 - 253

D41

330

3.23 - 58.6

49.5 - 240

D50

550

2.78 - 61.4

71.9 - 251



  • D11 - D41: Aluminum housing
  • D50: Gray cast iron housing



Documentation

View Here
